Raintap Rain Water Filter is simple, scientific and sensible rooftop rainwater harvesting filter which is compact, user friendly and requires negligible maintenance. These are flexible, truly modular and scalable for any size of roof. The filter element is of Nylon having mesh size of 130 micron, has long performance life. The element can be washed by anybody in case if it is clogged. There is unique safety feature built to notify clogging of element to avoid stagnation of water on roof. Unique back wash cap is given on the bottom of filter element to remove dried particles from filter. There are more than 25000 units installed across India and abroad.
Rainwater Harvesting is to save each drop of Rainwater falling on Roof or Surface for later usage or recharge.
Raintap is simple and scientific rainwater filter.
Raintap works on capillary action. Rainwater passes through vertical filter element leaving behind impurities.
Drain hole on top of filter element indicates clogging of filter element. This acts as safety feature.
Inlet: 110 mm (4”), Outlet: 110 mm (4”), Flush outlet: 50 mm (2”) provided with valve.
Raintap can cover 110 Sq. Meter (1200 Sq. ft.) of roof area.
Filter element is of 105 mm dia and 500 mm length. Filter element is made out of Nylon material.
One can take out filter element, wash it under a running tap simply by tapping it.
Raintap’s Height is 2 ft, Width is 1.5 ft and Depth is 200 mm (8”).
Its’ easy. Please keep valve on flush hole (opposite the inlet). This will allow draining of first rainfall. Once you close the valve, the rainwater will start flowing through outlet on Top.
